Description
|
Motor
|
Suspension
|
||||||||
|
Motor Type：10.5KW, AC motor
|
Front: Dual A-Arm 185.42mm(7.3″) Travel
|
||||||||
|
Electricity Consumption of Sigle Charge: 10Kwh
|
Rear: Dual A-Arm 185.42mm(7.3″) Travel
|
||||||||
|
Brakes
|
Tires
|
||||||||
|
Front/Rear Brakes: 4-Wheel Hydraulic Disc
|
Front Tires: 25×8.00-12
|
||||||||
|
Parking Brakes: Hand-Actuated
|
Rear Tires: 25×10.00-12
|
||||||||
|
Function/ Dimensions/ Capacities
|
|||||||||
|
Wheelbase: 1905mm
|
Drive System: 2WD
|
||||||||
|
Net Weight: 788kgs
|
Battery: 72V,150AH Lead acid colloidal battery
|
||||||||
|
Overall Vehicle Size: (L x W x H)2950x1430x1780mm
|
Overall Vehicle Load Weight: 999kgs
|
||||||||
|
Min Ground Clearance: 240mm
|
Hitch Towing Rating: 500kgs
|
||||||||
|
Min turning radius: 3.5m
|
Carrying capacity: 340KGS
|
||||||||
|
Max forward speed: 60(km/h)
|
Climbing ability: <=30°
|
||||||||
|
Cargo bed Dimensions: (L x W x H)1180×930×340mm
|
Cargo bed capacity: 185kgs
|
||||||||
